Product Summary

The CD4067BE is a 16-channel multiplexer with four binary control inputs, A, B, C, D and an inhibit input, arranged so that any combination of the inputs selects one switch.

Parametrics

CD4067BE absolute maximum ratings: (1)DC supply-voltage range: -0.5 to 20V; (2)input voltage range, all inputs: -0.5 to VDD+0.5V; (3)power dissipation per package, PD: 500mW; (4)device dissipation per output transistor: 100mW; (5)operating-temperature range, TA: -55 to 125℃; (6)storage temperature range, Tstg: -65 to 150℃; (7)lead temperature: 265℃.

Features

CD4067BE features: (1)low on resistance: 125Ω typ over 15 Vp-p signal-input range for VDD-VSS=15V; (2)high off resistance: channel leakage of ± 10pA typ at VDD-VSS=10V; (3)matched switch characteristics: RON=5Ω typ for VDD-VSS=15V; (4)very low quiescent power dissipation under all digital-control input and supply conditions: 0.2μW typ at VDD-VSS=10V; (5)binary address decoding on chip; (6)5V, 10V, and 15V parametric ratings; (7)100% tested for quiescent current at 20V; (8)standardized symmetrical output characteristics; (9)maximum input current of 1μA at 18V over full package temperature range; 100nA at 18V and 25℃; (10)meets all requirements of JEDEC tentative standard No 138.
