LMC6061

micropower operational amplifier, 8SOIC, 100kHz, 4.5 V ~ 15.5 V, RoHS Non-Compliant

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.10~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.10~0.50

PartNumber:: LMC6061

Brand:: National Semiconductor - NS | Pack: DIP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Andy's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-01-06

From Other Seller

Part Number:LMC6061
US $0.10 - 0.50
AT45DB161D-SU

US $1.50 - 3.50 / Piece
(0) Remove
AT25256AW-10SU-2.7

US $0.65 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LMC6061 is a precision single low offset voltage, micropower operational amplifier, capable of precision single supply operation. Performance characteristics include ultra low input bias current, high voltage gain, rail-to-rail output swing, and an input common mode voltage range that includes ground. These features, plus its low power consumption, make the LMC6061 ideally suited for battery powered applications. The applications of the LMC6061 include Instrumentation amplifier, Photodiode and infrared detector preamplifier, Transducer amplifiers, Hand-held analytic instruments, Medical instrumentation, D/A converter and Charge amplifier for piezoelectric transducers.

Parametrics

LMC6061 absolute maximum ratings: (1)Differential Input Voltage: ±Supply Voltage; (2)Voltage at Input/Output Pin: (V+) +0.3V, (V-) -0.3V; (3)Supply Voltage (V+-V-): 16V; (4)Lead Temperature: 260℃; (5)Storage Temp. Range: -65 to +150℃; (6)Junction Temperature: 150℃; (7)ESD Tolerance: 2 kV; (8)Current at Input Pin: ±10 mA; (9)Current at Output Pin: ±30 mA; (10)Current at Power Supply Pin: 40 mA.

Features

LMC6061 features: (1)Low offset voltage: 100 μV; (2)Ultra low supply current: 20 μA; (3)Operates from 4.5V to 15V single supply; (4)Ultra low input bias current: 10 fA; (5)Output swing within 10 mV of supply rail, 100k load; (6)Input common-mode range includes V-; (7)High voltage gain: 140 dB; (8)Improved latchup immunity.
