Product Summary

The 24C01JI is a 2-Wire Serial EEPROM. It provides 1024 bits of serial electrically erasable and programmable read only memory (EEPROM) organized as 128 words of 8 bits each. The 24C01JI is optimized for use in many industrial and commercial applications where low power and low voltage operation are essential. The 24C01JI is available in space saving 8-pin PDIP, 8-pin MSOP, 8-pin TSSOP, and 8-pin JEDEC SOIC packages and is accessed via a 2-wire serial interface.

Parametrics

24C01JI absolute maximum ratings: (1)Operating Temperature:-55℃ to +125℃; (2)Storage Temperature:-65℃ to +150℃; (3)Voltage on Any Pin with Respect to Ground:-1.0V to +7.0V; (4)Maximum Operating Voltage:6.25V; (5)DC Output Current: 5.0 mA.

Features

24C01JI features: (1)Low Voltage and Standard Voltage Operation: 5.0 (VCC = 4.5V to 5.5V), 2.7 (VCC = 2.7V to 5.5V), 2.5 (VCC = 2.5V to 5.5V), 1.8(VCC = 1.8V to 5.5V); (2)Internally Organized 128 x 8; (3)2-Wire Serial Interface; (4)Bidirectional Data Transfer Protocol; (5)100 kHz (1.8V, 2.5V, 2.7V) and 400 kHz (5V) Compatibility; (6)4-Byte Page Write Mode; (7)Self-Timed Write Cycle (10 ms max); (8)High Reliability; (9)Automotive Grade and Extended Temperature Devices Available; (10)8-Pin PDIP, 8-Pin MSOP, 8-Pin TSSOP and 8-Pin JEDEC SOIC Packages.
