Product Summary

The AD823AN is a dual precision, 16 MHz, JFET input op amp that can operate from a single supply of 3.0 V to 36 V or dual supplies of ±1.5 V to ±18 V. The AD823AN has true single supply capability with an input voltage range extending below ground in single-supply mode. Output voltage swing extends to within 50 mV of each rail for IOUT ≤ 100 μA, providing outstanding output dynamic range. The applications of the AD823AN include (1)Battery Powered Precision Instrumentation; (2)Photodiode Preamps; (3)Active Filters; (4)12- to 16-Bit Data Acquisition Systems; (5)Medical Instrumentation.

Parametrics

AD823AN absolute maximum ratings: (1)Supply Voltage: 36 V; (2)Internal Power Dissipation, Plastic Package (N): 1.3 W. Small Outline Package (R):0.9 W; (3)Input Voltage (Common Mode): ±VS; (4)Differential Input Voltage: ±1.2V; (5)Storage Temperature Range N, R: -65℃ to +125℃; (6)Operating Temperature Range: -40℃ to +85℃; (7)Lead Temperature Range (Soldering, 10 sec): 300℃.

Features

AD823AN features: (1)Single-supply operation; (2)High load drive; (3)Excellent ac performance on 2.6 mA/amplifier; (4)Good dc performance; (5)Low distortion: -108 dBc worst harmonic @ 20 kHz; (6)Low noise: 16 nV/√Hz @ 10 kHz; (7)No phase inversion with inputs to the supply rails.

Diagrams

AD823AN diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
AD823AN
AD823AN

Analog Devices Inc

IC OPAMP FET DUAL 16MHZ R-R 8DIP

Data Sheet

1-25: $2.83
25-100: $2.39
100-250: $2.30
250-500: $2.25
500-1000: $2.21
1000-5000: $2.16
AD823ANZ
AD823ANZ


IC OPAMP JFET R-R DUAL LN 8DIP

Data Sheet

0-1: $3.81
1-10: $3.43
10-25: $3.12
25-100: $2.82
100-250: $2.59
250-500: $2.36
500-1000: $2.06
1000-2500: $2.03
