M29W040B

4 Mbit, non-volatile memory, 32PLCC, 55ns, 2.7 V ~ 3.6 V, RoHS Compliant

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.10~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.10~0.50

PartNumber:: M29W040B

Brand:: STMicroelectronics - ST | Pack: PLCC | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Andy's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-01-06

From Other Seller

Part Number:M29W040B
US $0.10 - 0.50
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The M29W040B is a 4 Mbit (512Kb×8) non-volatile memory that can be read, erased and reprogrammed. These operations can be performed using a single low voltage (2.7 to 3.6V) supply. On power-up the memory defaults to its Read mode where it can be read in the same way as a ROM or EPROM. The M29W040B is fully backward compatible with the M29W040. The memory is divided into blocks that can be erased independently so it is possible to preserve valid data while old data is erased.

Parametrics

M29W040B absolute maximum ratings: (1)TA, Ambient Operating Temperature (Temperature Range Option 1): 0 to 70℃; Ambient Operating Temperature (Temperature Range Option 6): –40 to 85℃; (2)TBIAS, Temperature Under Bias: –50 to 125℃; (3)TSTG, Storage Temperature: –65 to 150℃; (4)VIO, Input or Output Voltage: –0.6 to 4 V; (5)VCC, Supply Voltage: –0.6 to 4 V; (6)VID, Identification Voltage: –0.6 to 13.5 V.

Features

M29W040B features: (1)single 2.7 to 3.6V supply voltage for program, erase and read operations; (2)access time: 55ns; (3)programming time: 10μs per Byte typical; (4)8 uniform 64 Kbytes memory blocks; (5)program/erase controller: Embedded Byte Program algorithm; Embedded Multi-Block/Chip Erase algorithm; Status Register Polling and Toggle Bits; (6)erase suspend and resume modes: Read and Program another Block during Erase Suspend; (7)unlock bypass program command: Faster Production/Batch Programming; (8)low power consumption: Standby and Automatic Standby; (9)100,000 program/erase cycles per block; (10)20 years data retention: Defectivity below 1 ppm/year; (11)electronic signature: Manufacturer Code: 20h; Device Code: E3h.
