Product Summary
The MC671L is a Motorola MHTL integrated circuit which is desgined to meet the requirements of industrial applications because of the outstanding noise immunity.
Parametrics
MC671L absolute maximum ratings: (1)Power supply voltage: 18V continuous; pulsed, 1.0 s 20V; (2)Input voltage: -1.0 to 18 V; (3)Output current: 30 mA; (4)Input reverse current@18V: 0.5 mA; (5)Operating temperature: -30 to +75 ℃; (6)Storage temperature: -55 to +125 ℃.
Features
MC671L charanteristics: (1)Triple 3-input NAND Gate; (2)Loading factor each output: 10; (3)Propagation delay ns typ: 110; (4)Power dissipation: 132/39 mW; (5)Case: 632,646.
Diagrams
 |
