Product Summary

The LM307P is a high-performance operational amplifier featuring very low input bias current and input offset voltage and current to improve the accuracy of high-impedance circuits using these devices. The high common-mode input voltage range and the absence of latch-up make the LM307P ideal for voltage follower applications. The devices are short-circuit protected and the internal frequency compensation ensures stability without external components.

Parametrics

LM307P absolute maximum ratings: (1)Supply voltage, VCC +: 18 V; (2)Supply voltage, VCC –: –18 V; (3)Differential input voltage: ±30 V; (4)Input voltage: ±15 V; (5)Operating free-air temperature range: 0 to 70℃; (6)Storage temperature range: –65 to 150℃; (7)Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds: 260℃.

Features

LM307P features: (1)Low Input Currents; (2)No Frequency Compensation Required; (3)Low Input Offset Parameters; (4)Short-Circuit Protection; (5)No Latch-Up; (6)Wide Common-Mode and Differential Voltage Ranges.

Diagrams

LM307P symbol
